Automatic Cap Eyelet Punching And Stitching Sewing Machine

  • GT430D-CH

  • KINGMAX

  • One Needle

  • 3200

Availability:

Product Descriptions

Automatic Cap Eyelet Punching and Stitching Pattern Sewing Machine is a specialized piece of equipment used in the manufacturing of caps and hats. It's designed to automate the process of punching eyelets into the caps and stitching patterns onto them, streamlining production and ensuring consistency in the finished products. It have a control panel where operators can set various parameters such as stitching patterns, stitch length, and speed. Suitable for automatic eyelet punching and sewing on caps, trousers, shoes as well as other apparel products (punching dies can be changed).


Features

  • Automatic cap eyelet punching and stitch pattern sewing machine

  • The different size punching dies available as the option

  • The Dahao control system with the strong direct-drive motor

  • The touchable panel with the input function and USB port


Specifications

Model

GT430D-CH

Max. Sewing Speed

3200SPM

Sewing Area

40X30mm

Max.Central Foot Lift

20mm

The Max.Stitch Length

12.70mm

The Adjusted Central Foot Range

0-3.50mm

Hook

Double-capacity shuttle hook

Needle

DPx5   #16


Product Details

Automatic Cap Eyelet Punching and Stitching Pattern Sewing Machine
