GT199/146 Series
KINGMAX
One Needle
Top and Bottom Feed
1700
Availability: | |
---|---|
Product Descriptions
This series machines are single needle, high speed, lockstitch zigzag industrial sewing machines, equipped with the large horizontal axis rotary hook and large bobbin, reverse lever, 3 interchanged cams(the standard kits) can realize one step two points zigzag, 2 steps 3 points zigzag and 3 steps 4 points zigzag. GT199 is only bottom feed version zigzag machine, and GT146 is bottom feed and top feed(walking foot) version zigzag machines, especially both GT199/146-B(only one step and two points zigzag) adopts the differential feeding structure, which make the max. zigzag width can up to 13mm. GT199-2 is the double needle zigzag machine with the bottom feed and roller feet. Suitable for sewing medium to heavy weight materials, such as bags, shoes, gloves and diving dress etc.
Features
High speed, lockstitch zigzag sewing machine.
Large horizontal axis rotary hook and large bobbin.
The top feed with walking foot avoids the needle skip.
Various models for the different demands.
One universal medium and heavy weight zigzag machines for the bag, shoes factories.
Specifications
Model | GT199 | GT146 | GT199/146-B | GT199-2 |
The Max. Sewing Speed | 1700SPM | |||
Stitch Patterns | 1 step 2 points, 2 steps 3 points, 3 steps 4 points | 1 step 2 points | ||
The Max. Zigzag Width | 10mm | 13mm | 4mm | |
The Max. Foot Lift | 13mm | |||
The Zigzag Stitch Length | 5mm | |||
Hook | Large horizontal axis rotary hook | |||
Needle | DPx17 #14-22 |
