Products Descriptions
25 inch long arm direct-driven walking foot leather sewing machine is designed for manufacturers who require higher efficiency, precise control, and stable sewing performance when producing large leather products and oversized assemblies. In large-scale leather manufacturing, conventional belt-driven sewing machines may suffer from slower response, higher energy consumption, and increased maintenance. When handling oversized workpieces limited working space and frequent material repositioning can also reduce production efficiency and sewing consistency.
The KINGMAX 25 inch long arm direct-driven walking foot leather sewing machine combines a high-efficiency direct-drive servo motor with an extra-long 25-inch working space and a synchronized walking foot feeding system. This integrated design provides instant machine response, accurate needle positioning, stable material feeding, and lower operating costs, making it an ideal solution for continuous industrial production of large leather products.
I. Application Areas
- Automotive Interior Manufacturing：Car seats, Door panels, Dashboard covers, Interior trim.
- Aircraft Upholstery：Aircraft seating, Cabin leather panels, Aviation upholstery.
- Marine Furniture：Yacht seating, Marine cushions, Boat upholstery.
- Industrial Covers & Large Leather Products：Equipment covers, Protective covers, Large leather bags, Thick leather assemblies.
Applications
Marine Furniture
Automotive Interiors
Aircraft Upholstery
Main Features & Benefits
- Direct-Drive Servo System：The integrated direct-drive motor delivers immediate start-up, precise speed control, and accurate needle positioning while reducing maintenance compared with conventional belt-driven machines.
✓ Faster machine response
✓ Lower energy consumption
✓ Reduced vibration and operating noise
✓ Minimal maintenance requirements
- 25 Inch Extended Working Space：The extra-long sewing arm offers greater accessibility for oversized leather panels and bulky products.
✓ Easier handling of large workpieces
✓ Less material repositioning
✓ Improved productivity on long seams
- Walking Foot Feeding System：The synchronized walking foot mechanism ensures smooth and even feeding of leather and multi-layer materials.
✓ Prevents material shifting
✓ Consistent stitch quality
✓ Stable sewing on thick leather
- Industrial Automation Features：Equipped with automatic thread trimming and optional synchronized rear puller to improve production efficiency.
✓ Cleaner thread finishing
✓ Reduced manual operation
✓ Better material control for long sewing projects
✓ Suitable for continuous production
Products Specifications
|
Model |
GC1510DL-25 |
GC1510DL-25-7 |
GC1560DL-25 |
GC1560DL-25-7 |
|
Number of Needle |
1 needle |
2-needle |
||
|
Max.Sewing Speed |
2500SPM |
|||
|
Max.Stitch Length |
9mm |
9mm |
9mm |
9mm |
|
Max.Lift of the Presser Foot |
16mm |
|||
|
Hook |
Double capacity vertical axis rotary hook |
|||
|
Safety Clutch |
Yes |
|||
|
Needle Gauge |
none |
6.4, 7.9 , 9.5, 12.70mm |
||
|
Working Space |
635x100mm |
|||
|
Needle |
DPx17, 19-23# |
|||
FAQ
Q1:Why choose a 25 inch long arm sewing machine instead of an 18 inch model?
A1:A 25-inch long arm provides a larger sewing area and deeper reach, making it easier to sew oversized products such as automotive interiors, aircraft upholstery, marine cushions, and industrial covers with fewer material adjustments.
Q2:How does the direct-drive system improve production efficiency?
A2:The integrated direct-drive motor delivers instant start-up, accurate needle positioning, and stable speed control while reducing energy consumption, vibration, and routine maintenance compared with traditional belt-driven machines.
Q3:Is this machine suitable for continuous heavy-duty production?
A3:Yes. The reinforced machine structure, walking foot feeding system, and direct-drive technology are designed for long production runs, providing stable performance even when sewing thick and multi-layer materials continuously.
Q4:Can this machine be configured for different production requirements?
A4:Yes. Single-needle or double-needle versions, automatic thread trimming, and an optional synchronized rear puller are available to match different products and manufacturing processes.
Q5:How can KINGMAX help with machine selection?
A5:Our engineering team recommends the most suitable machine configuration based on your product size, material thickness, sewing process, and production capacity, ensuring the best balance of efficiency and sewing quality.
