Name: China Automatic Big Bag Loop Stitching Sewing Machine Manufacturers Suppliers - Factory Direct Price - KINGMAX
Brand: KINGMAX
SKU: 264212116

Description

Technical Parameters

Products Features

The professional automatic big bag looping sewing machine.
Large sewing area: 500x200mm.
The fashion touchable operation panel with the edited function.
Automatic thread trimming function.
Extra large rotary hook and large bobbin with the low bobbin thread change.

Products Descriptions & Details

This is one computerized automatic big bag loop sewing machine, which sewing area is 500x200mm. High speed, long arm machine head with the large working space under the arm, the linear rail feeding structure, the front small handle wheel, the top emergency stop, extra large rotary hook with large bobbin, which can reduce the bobbin thread changing frequency, the unique top and bottom clamp holds the big bag loop well. The strong durable control system with the mini direct-driven servo motor, multi-languages provided, the touchable panel has the input function with the USB port. This machine is mainly designed for the big bag loop sewing with the high output, which solve the regular mechanical loop sewing machine's low efficiency in the most big bag factories. High working efficiency, labor cost-saving, your best choice for the loop sewing. It also can sew the other heavy duty products with patterns, such as webbing, lifting straps, cargo slings etc.

Machine Front

Sewing Detail

Stitch Sample

Products Specifications

Model	PSM-E5020-LS
Number of Needle	1 needle
Max.Sewing Speed	2800SPM
Sewing Area	500x200mm
Max.Stitch Length	12.70mm.
Lift of the Medium Presser Foot	20mm
Max.Sewing Thickness	20mm
Needle (Standard)	DPx17
Hook Type	Extra large rotary hook
